How to Deploy Zabbix Server on Hosting?

13 minutes read

To deploy Zabbix server on hosting, follow these steps:

  1. Choose a suitable hosting provider: Look for a hosting provider that supports Linux operating system and meets the requirements for running Zabbix server.
  2. Select a hosting plan: Choose an appropriate hosting plan with sufficient resources such as CPU, RAM, and storage to meet your monitoring needs. It should also provide access to the server's terminal.
  3. Set up a Linux server: Once you have signed up for hosting, create a Linux-based virtual private server (VPS) or dedicated server, depending on your requirements. Install the desired Linux distribution, such as Ubuntu, CentOS, or Debian.
  4. Update the server: Update the server's packages and dependencies to the latest versions using package management tools like "apt" or "yum".
  5. Install the necessary software: Zabbix server requires a web server, database server, and PHP. Install the required software packages such as Apache or Nginx as the web server, MySQL or PostgreSQL as the database server, and PHP with necessary extensions.
  6. Configure the database: Create a database and user for Zabbix server in the chosen database server. Grant the necessary privileges to the user for managing the database.
  7. Install Zabbix server: Download the Zabbix server package from the official website or use package management tools to install it. Follow the installation instructions provided by Zabbix.
  8. Configure Zabbix server: Edit the Zabbix server configuration file to specify the database connection details, server settings, and other parameters as per your requirements.
  9. Start Zabbix server: After configuring the server, start the Zabbix server service to begin monitoring.
  10. Access the Zabbix web interface: Open a web browser and enter the server's IP address or domain name followed by the Zabbix web interface directory. Complete the initial setup by providing the necessary details such as language preference, administrator credentials, and database connection information.

Once the Zabbix server is successfully deployed, you can start adding hosts, configuring monitoring items, and creating dashboards to monitor your IT infrastructure.

Exceptional Cloud Hosting Providers in 2024


Rating is 5 out of 5



Rating is 5 out of 5



Rating is 4.8 out of 5



Rating is 4.7 out of 5


What is a Zabbix template and how to create one?

A Zabbix template is a pre-defined set of configuration settings, triggers, and graphs that can be easily applied to multiple hosts in a Zabbix monitoring system. Templates simplify the process of configuring and deploying monitoring items across multiple hosts with similar functionality.

To create a Zabbix template, follow these steps:

  1. Log in to your Zabbix web interface with administrative privileges.
  2. Go to "Configuration" and select "Templates" from the dropdown menu.
  3. Click on the "Create template" button.
  4. Provide a name and optional description for the template.
  5. Add template groups and link relevant templates if needed.
  6. Configure template screens if required.
  7. Specify template macros for dynamic settings.
  8. Define template linkage if necessary.
  9. Add items, triggers, graphs, and other necessary components to the template by clicking on their respective tabs and using the "Create item"/"Create trigger"/"Create graph" buttons.
  10. Customize and configure each component according to your monitoring requirements.
  11. Save the template.

Once the template is created, you can apply it to multiple hosts by navigating to their specific configurations and linking the template to them. This ensures consistent monitoring settings across multiple hosts with similar functionality or requirements.

How to configure email notifications on Zabbix server?

To configure email notifications on Zabbix server, follow these steps:

  1. Install and configure a mail transfer agent (MTA) on the Zabbix server. Popular options include Sendmail, Postfix, and Exim.
  2. Determine the SMTP server address and port to use for sending email notifications.
  3. Log in to the Zabbix web interface as an administrator.
  4. Go to "Administration" > "Media types" and click on "Email" to configure the email media type.
  5. Enter a name for the email media type, such as "Email notifications".
  6. In the "SMTP server" field, enter the address of the SMTP server.
  7. If necessary, specify the port number in the "SMTP server port" field.
  8. Configure other fields as desired, including the "Connection security" option (e.g. STARTTLS) and "SMTP helo" field.
  9. Specify the "Username" and "Password" if required for SMTP authentication.
  10. In the "SMTP email" field, enter the email address from which you want to send notifications.
  11. Click on the "Add" button to save the email media type.
  12. Go to "Administration" > "Users" and select the user for whom you want to enable email notifications.
  13. In the "Media" tab, click on "Add" and select the email media type you configured earlier.
  14. Enter the email address to which you want to send notifications in the "Send to" field.
  15. Configure the other fields as desired, including "Severity" and "Enabled" options.
  16. Save the user settings.
  17. Go to "Configuration" > "Actions" and click on "Event source" to create a new action.
  18. Enter a name for the action and specify the conditions for when the action should be triggered.
  19. In the "Operations" tab, click on "Add" and select "Send message" as the operation type.
  20. Select the user to whom you want to send the email notification.
  21. Enter the subject and message for the email notification.
  22. Save the action.
  23. Test the configuration by generating an event that matches the conditions specified in the action, and check if the email notification is received.

Note: It is crucial to ensure that the Zabbix server has connectivity to the SMTP server and that any necessary firewall rules or network configurations are in place to allow email traffic.

What is the importance of database optimization in Zabbix deployment?

Database optimization is crucial in a Zabbix deployment for several reasons:

  1. Improved performance: Zabbix stores a large amount of data in its database, which can lead to performance issues if not optimized properly. Database optimization helps in enhancing the performance of the Zabbix system by addressing issues like slow response times, high read/write loads, and database bottlenecks.
  2. Efficient data retrieval: Zabbix relies heavily on database queries to retrieve historical data, generate reports, and visualize monitoring data. Optimizing the database ensures that these queries are executed quickly and efficiently, resulting in faster data retrieval and analysis.
  3. Scalability: As the number of monitored devices and metrics increases, the database can become a bottleneck if not optimized. Proper indexing, query optimization, and schema design allow the database to handle larger data volumes and scale smoothly as the monitoring environment expands.
  4. Reduced resource utilization: Database optimization can help reduce the consumption of system resources like CPU, memory, and disk I/O. By optimizing queries and reducing database load, fewer resources are required, leading to better overall system performance and cost savings.
  5. Enhanced system stability: An optimized database minimizes the risk of system failures, crashes, or slowdowns caused by database-related issues. By ensuring that the database is running efficiently, the overall stability and reliability of the Zabbix deployment are improved.
  6. Data retention: Zabbix typically retains a large amount of historical data, which can quickly grow and consume significant storage space. Database optimization techniques such as data partitioning, archiving, and purging help manage data growth, optimize storage usage, and ensure efficient data retention for long periods.

In summary, database optimization is crucial in a Zabbix deployment to improve performance, ensure efficient data retrieval and analysis, scale the system, reduce resource utilization, enhance system stability, and manage data retention effectively.

What is the recommended server configuration for Zabbix deployment?

The recommended server configuration for Zabbix deployment depends on several factors, including the number of monitored hosts, the number of data points collected, the desired level of performance, and the expected growth of the monitoring environment.

However, here are some general guidelines for the server configuration:

  1. CPU: A multi-core CPU with a clock speed of at least 2 GHz is recommended. The number of cores will depend on the expected load and the number of monitored hosts.
  2. RAM: The recommended amount of RAM depends on the number of monitored hosts and data points. As a starting point, allocate at least 4 GB of RAM, but it may need to be increased for larger deployments.
  3. Disk space: Allocate enough disk space to store historical data and logs. The amount of disk space required will depend on the retention period of historical data and the volume of collected data.
  4. Network: A network interface with sufficient bandwidth to handle the incoming and outgoing traffic is necessary. It should be connected to the network where the monitored hosts are located.
  5. Operating System: Zabbix supports various operating systems, including Linux distributions (such as CentOS, Ubuntu, and Debian), as well as Windows Server. Choose an operating system that is well-supported and familiar to your team.
  6. Database: Zabbix supports multiple database management systems (DBMS), such as MySQL, PostgreSQL, and Oracle. The choice of DBMS depends on factors like performance requirements, high availability, and familiarity with the system.
  7. High Availability: For larger deployments or critical monitoring environments, it is recommended to implement high availability by using redundant server configurations, database replication, and load balancing.

These are general recommendations, and it's important to consider specific requirements and performance expectations when designing the server configuration for a Zabbix deployment. It's also a good practice to regularly monitor the performance of your Zabbix server and adjust the configuration if needed.

What is low-level discovery in Zabbix server and how to utilize it?

Low-level discovery (LLD) is a feature in Zabbix server that allows automatic detection and monitoring of new entities or elements in a system, without the need for manual configuration. It is particularly useful in dynamic environments where new resources are added or removed frequently, such as virtual machines, network interfaces, or storage devices.

To utilize LLD in Zabbix server, follow these steps:

  1. Define a discovery rule: In the Zabbix server web interface, go to Configuration -> Discovery -> Discovery rules. Click on "Create discovery rule" to define a rule that matches the desired items based on certain criteria like SNMP OID, regular expressions, or script execution. The rule specifies how Zabbix should discover elements and what information to collect.
  2. Configure item prototypes: Within the discovery rule, create item prototypes that define what data should be collected for each discovered element. This can include performance metrics, status checks, or any other relevant information. Item prototypes can be configured to collect data from SNMP, the Zabbix agent, JMX, IPMI, or other protocols.
  3. Define trigger prototypes (optional): If you want to generate alerts based on discovered items, define trigger prototypes. These trigger prototypes will create triggers for each discovered item matching specific conditions. For example, you can set a trigger to fire if the disk usage exceeds a certain threshold.
  4. Create host prototypes: Host prototypes define how the discovered elements should be treated as hosts in Zabbix. They include properties like host name, IP address, or other identifying attributes. Host prototypes can be used to group related elements or apply templates or macros to all discovered hosts.
  5. Schedule discovery: Associate a time interval or event trigger with the discovery rule to determine how frequently the discovery process should run. This ensures that Zabbix periodically checks for new elements and monitors them accordingly.

By utilizing LLD, Zabbix server can automatically discover, monitor, and alert on new elements as they appear in the monitored environment, reducing manual effort and providing real-time visibility into the system.

What is the difference between Zabbix server and Zabbix proxy?

Zabbix server and Zabbix proxy are two components of the Zabbix monitoring system. Here are the differences between them:

  1. Functionality: Zabbix server is the central component that performs data collection, processing, storage, and presentation. It manages all aspects of monitoring, including configuring monitoring targets, collecting and storing data, and generating alerts. Zabbix proxy acts as an intermediary between monitored devices and the server. It can perform data collection, preprocessing, and buffering of monitoring data, reducing the workload on the server.
  2. Scalability and Performance: Zabbix server is the core component and typically handles all monitoring tasks. As the number of monitored devices or the volume of monitoring data increases, the server may become overloaded, affecting performance. Zabbix proxy helps to distribute the monitoring workload and improve performance. Proxies can be deployed closer to monitored devices to collect and process data locally, reducing network latency and server load.
  3. Data Collection: Zabbix server directly collects data from monitored devices using various methods like SNMP, agent-based, or agentless monitoring. Zabbix proxy can also collect data from devices using the same methods as the server. It stores the collected data locally and then sends it to the server for further processing and storage.
  4. Network Segmentation: Zabbix server is typically deployed in a central location and communicates directly with monitored devices over the network. Zabbix proxy can be deployed at remote locations, separate network segments, or sites with limited connectivity. It collects data from devices in its local network segment and then sends it to the server.
  5. Redundancy and Failover: Zabbix server can be configured in a cluster for high availability, where multiple servers work together and share the monitoring workload. If one server fails, others can take over. Zabbix proxy can also be used in high availability setups, where multiple proxies are configured to monitor the same set of devices. If one proxy fails, others can continue monitoring.

In summary, Zabbix server is the central component responsible for monitoring, data storage, and presentation, while Zabbix proxy acts as an intermediary to distribute the workload, improve performance, and enable monitoring in remote locations.
