How to Customize MATLAB Plots And Figures?

10 minutes read

To customize MATLAB plots and figures, you can use various functions and properties to modify different aspects of the plot appearance. Here are some options to consider:

  1. Choosing plot colors: Use the plot function's color argument to specify the line color. Modify individual line colors with the set function and the 'Color' property.
  2. Adjusting line styles: Define different line styles with the plot function's line style argument. Modify line styles using the set function and the 'LineStyle' property.
  3. Adding labels: Use the xlabel and ylabel functions to add labels to the x and y axes, respectively. Set the plot title with the title function.
  4. Changing line widths: Adjust the line width with the plot function's linewidth argument. Modify line widths using the set function and the 'LineWidth' property.
  5. Modifying marker styles: Use the plot function's marker argument to specify marker styles. Adjust marker size with the plot function's markersize argument.
  6. Controlling axes appearance: Customize axis limits using the xlim and ylim functions. Modify the axis tick marks with the xticks and yticks functions.
  7. Adding a legend: Use the legend function to specify a legend with labels corresponding to different plot elements.
  8. Adjusting figure dimensions: Resize the figure window using the figure function's 'Position' property. Set the figure size for saving using the saveas function's 'PaperSize' property.


These are just a few of the many possibilities for customizing MATLAB plots and figures. By using these functions and properties, you can create visualizations tailored to your specific requirements or preferences.

Best Matlab Books to Read in 2024

1
MATLAB for Engineers

Rating is 5 out of 5

MATLAB for Engineers

2
Essential MATLAB for Engineers and Scientists

Rating is 4.9 out of 5

Essential MATLAB for Engineers and Scientists

3
MATLAB and Simulink Crash Course for Engineers

Rating is 4.8 out of 5

MATLAB and Simulink Crash Course for Engineers

4
MATLAB: A Practical Introduction to Programming and Problem Solving

Rating is 4.7 out of 5

MATLAB: A Practical Introduction to Programming and Problem Solving

5
MATLAB For Dummies (For Dummies (Computer/Tech))

Rating is 4.6 out of 5

MATLAB For Dummies (For Dummies (Computer/Tech))

6
Differential Equations with Matlab

Rating is 4.5 out of 5

Differential Equations with Matlab

7
Matlab: A Practical Introduction to Programming and Problem Solving

Rating is 4.4 out of 5

Matlab: A Practical Introduction to Programming and Problem Solving

8
Matlab: A Practical Introduction to Programming and Problem Solving

Rating is 4.3 out of 5

Matlab: A Practical Introduction to Programming and Problem Solving

9
MATLAB and Simulink In-Depth: Model-based Design with Simulink and Stateflow, User Interface, Scripting, Simulation, Visualization and Debugging

Rating is 4.2 out of 5

MATLAB and Simulink In-Depth: Model-based Design with Simulink and Stateflow, User Interface, Scripting, Simulation, Visualization and Debugging


How to customize the line style in a MATLAB figure?

To customize the line style in a MATLAB figure, you can use the LineStyle property of a plot. Here are the steps to do it:

  1. Create a plot using the plot() function or any other plot command in MATLAB.
  2. Use the LineStyle property to specify the desired line style for the plot. You can set it to one of the following values: '-' : Solid line (default) '--' : Dashed line ':' : Dotted line '-.' : Dash-dot line
  3. Assign the desired line style to the plot by setting the LineStyle property to the desired value. For example: plot(x, y, 'LineStyle', '--');


Here is an example that demonstrates how to customize the line style in a MATLAB figure:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
% Create some sample data
x = linspace(0, 2*pi, 100);
y1 = sin(x);
y2 = cos(x);

% Create a figure and plot the data with different line styles
figure
hold on
plot(x, y1, 'LineStyle', '-');     % Solid line
plot(x, y2, 'LineStyle', '--');    % Dashed line
plot(x, y1+y2, 'LineStyle', ':');  % Dotted line
plot(x, y1-y2, 'LineStyle', '-.'); % Dash-dot line

% Add labels and legend
xlabel('x')
ylabel('y')
legend('sin(x)', 'cos(x)', 'sin(x)+cos(x)', 'sin(x)-cos(x)')

% Customize the axis and title
axis([0, 2*pi, -2, 2])
title('Custom Line Styles')


This will create a MATLAB figure with four plots, each having a different line style.


How to add a title to a MATLAB plot?

To add a title to a MATLAB plot, you can use the title function. Here's how you can do it:

  1. Create a plot using any MATLAB plotting function such as plot, scatter, or bar. For example:
1
2
3
x = 1:10;
y = x.^2;
plot(x, y);


  1. After creating the plot, use the title function to add a title to the plot. Specify the title text as the input to the function. For example:
1
title('Plot of x^2');


  1. Run the code to display the plot with the added title. The title will appear at the top of the plot.


You can customize the title appearance further by using additional options of the title function, such as specifying the font size, font weight, or font name.


How to create a bar plot in MATLAB?

To create a bar plot in MATLAB, you can follow these steps:

  1. Define the data you want to plot. For example, let's say you have a vector x containing the x-axis values and a vector y containing the corresponding y-axis values.
1
2
x = [1 2 3 4 5];
y = [10 15 12 7 9];


  1. Use the bar function to create the bar plot. Pass the x and y values as input arguments to the bar function.
1
bar(x, y);


  1. Customize the appearance of the bar plot if desired. You can change the color, add labels, adjust the axis limits, and more. Here are a few common customization options:
  • To change the color of the bars, you can use the 'FaceColor' property. For example, to set the bars to blue, add the following line of code:
1
bar(x, y, 'FaceColor', 'b');


  • To add labels to the x-axis and y-axis, you can use the xlabel and ylabel functions. For example:
1
2
xlabel('X-axis');
ylabel('Y-axis');


  • To adjust the axis limits, you can use the xlim and ylim functions. For example, to set the x-axis limits from 0 to 6, add the following line of code:
1
xlim([0 6]);


  1. Display the plot. Use the title function to add a title to the plot if desired.
1
title('Bar Plot');


Here is an example of the complete code:

1
2
3
4
5
6
7
8
x = [1 2 3 4 5];
y = [10 15 12 7 9];

bar(x, y, 'FaceColor', 'b');
xlabel('X-axis');
ylabel('Y-axis');
xlim([0 6]);
title('Bar Plot');


Running this code will generate a bar plot with the specified data and customizations.
