How Spring Boot Works Internally?

15 minutes read

Spring Boot is a popular framework built on top of the Spring framework, designed to simplify the development of Java applications. It follows the principle of convention over configuration, allowing developers to quickly and easily create standalone, production-grade Spring-based applications. Understanding how Spring Boot works internally can offer insight into its core functioning.


At its core, Spring Boot leverages various components and technologies to deliver its functionality. When a Spring Boot application starts, it performs several initialization steps and follows a specific startup process.


Firstly, the main class of the application is executed, which kicks off the application startup process. Spring Boot uses an embedded servlet container (like Tomcat or Jetty) to handle HTTP requests. The servlet container is automatically configured based on the application's classpath and dependencies.


Next, Spring Boot creates an instance of the ApplicationContext, which acts as the central interface between the application code and the Spring framework. The ApplicationContext is responsible for managing application components, wiring dependencies, and providing access to various features like configuration properties.


Spring Boot heavily relies on the concept of "auto-configuration." It automatically configures certain components based on the project's classpath and dependencies. Auto-configuration is achieved using Spring Boot starters, which are special dependencies that bring in pre-configured components, based on the technologies used in the project (e.g., database starter for database connectivity).


During startup, Spring Boot scans the classpath for certain annotations, such as @Configuration, @ComponentScan, and @EnableAutoConfiguration. These annotations enable Spring Boot to identify components, configuration classes, and properties that need to be picked up and used for application bootstrapping.


Additionally, Spring Boot provides many handy features like externalized configuration through properties or YAML files, intelligent logging configuration, conditional beans, and profiles that allow application customization based on the environment.


Internally, Spring Boot leverages the extensive Spring framework ecosystem and its various modules to deliver its functionality. This includes components like Spring Core, Spring MVC, Spring Data, Spring Security, and more. These modules provide robust support for dependency injection, web development, data access, security, and other enterprise features.


By understanding how Spring Boot works internally, developers can effectively utilize its capabilities and build applications quickly with less configuration overhead. Its opinionated approach and auto-configuration make it a popular choice for developers seeking productivity and simplicity in Java application development.

Best Spring Boot Books to Read in October 2024

1
Full Stack Development with Spring Boot and React: Build modern and scalable web applications using the power of Java and React, 3rd Edition

Rating is 5 out of 5

Full Stack Development with Spring Boot and React: Build modern and scalable web applications using the power of Java and React, 3rd Edition

2
Spring Boot Persistence Best Practices: Optimize Java Persistence Performance in Spring Boot Applications

Rating is 4.9 out of 5

Spring Boot Persistence Best Practices: Optimize Java Persistence Performance in Spring Boot Applications

3
Spring Boot in Action

Rating is 4.8 out of 5

Spring Boot in Action

4
Spring Boot: Up and Running: Building Cloud Native Java and Kotlin Applications

Rating is 4.7 out of 5

Spring Boot: Up and Running: Building Cloud Native Java and Kotlin Applications

5
Learning Spring Boot 3.0: Simplify the development of production-grade applications using Java and Spring, 3rd Edition

Rating is 4.6 out of 5

Learning Spring Boot 3.0: Simplify the development of production-grade applications using Java and Spring, 3rd Edition

6
Spring in Action, Sixth Edition

Rating is 4.5 out of 5

Spring in Action, Sixth Edition

7
Modern API Development with Spring and Spring Boot: Design highly scalable and maintainable APIs with REST, gRPC, GraphQL, and the reactive paradigm

Rating is 4.4 out of 5

Modern API Development with Spring and Spring Boot: Design highly scalable and maintainable APIs with REST, gRPC, GraphQL, and the reactive paradigm

8
Spring Boot and Angular: Hands-on full stack web development with Java, Spring, and Angular

Rating is 4.3 out of 5

Spring Boot and Angular: Hands-on full stack web development with Java, Spring, and Angular


What is the underlying framework used by Spring Boot?

The underlying framework used by Spring Boot is the Spring Framework. Spring Boot is built on top of the Spring Framework, which provides a comprehensive infrastructure for developing Java applications.


What is the purpose of Spring Boot?

The purpose of Spring Boot is to simplify the development process of creating stand-alone, production-grade Spring-based applications. It provides a convention-over-configuration approach, allowing developers to quickly set up and configure Spring applications with minimal effort. Spring Boot automates the configuration and dependency management, eliminating the need for manual configuration, and saves a significant amount of development time. It also includes various production-ready features such as metrics, health checks, and externalized configuration to help developers build robust and scalable applications.


How does Spring Boot leverage embedded servers?

Spring Boot leverages embedded servers by packaging them directly into the application as a dependency. This allows developers to create self-contained and executable JAR files, which include the embedded server.


When the application is started, the embedded server is automatically initialized and started along with the application. Spring Boot provides auto-configuration for various types of embedded servers, such as Tomcat, Jetty, and Undertow. Depending on the dependencies present in the project, Spring Boot configures the appropriate server for deployment.


By using embedded servers, developers can easily deploy their Spring Boot applications without requiring installation or configuration of a separate server environment. This makes it convenient for packaging and deploying applications in a variety of deployment scenarios, including standalone applications, microservices, and containerized environments.

Best Cloud Providers to Host Java Spring Boot in 2024

1
AWS

Rating is 5 out of 5

AWS

2
DigitalOcean

Rating is 4.9 out of 5

DigitalOcean

3
Vultr

Rating is 4.8 out of 5

Vultr

4
Cloudways

Rating is 4.7 out of 5

Cloudways


How does Spring Boot handle logging?

Spring Boot provides logging support through the Spring Boot Starter for logging. It includes Logback as the default logging framework, but also supports others like Log4J2 and JUL (Java Util Logging).


The logging configuration is generally done through the application.properties or application.yml file, where you can specify the logging levels and patterns for different loggers.


Spring Boot uses a predefined set of loggers for different components and libraries. It also allows you to define your custom loggers and configure them according to your requirements. These loggers can be used to capture different levels of log messages like debug, info, warn, and error.


By default, the log output is printed to the console. However, you can configure it to log to different appenders like rolling files, databases, or remote services. You can also configure log rotation, file size limits, and other log file management settings.


Spring Boot also provides an actuator endpoint (e.g., /actuator/loggers) that allows you to view and modify the logging configuration at runtime. This feature is especially useful in production environments where you might want to adjust the logging levels without restarting the application.


Overall, Spring Boot offers flexible and powerful logging capabilities that can be easily configured and customized to meet your logging needs.


How does Spring Boot simplify the configuration process?

Spring Boot simplifies the configuration process in the following ways:

  1. Opinionated Defaults: Spring Boot comes with a set of opinionated defaults and auto-configuration that automatically configures the application based on common use cases. This eliminates the need for developers to manually configure every aspect of their application.
  2. Externalized Configuration: Instead of hardcoding configuration values within the application code, Spring Boot allows developers to externalize the configuration using properties or YAML files. These externalized configuration files can be easily modified without needing to recompile or redeploy the application.
  3. Auto-Configuration: Spring Boot automatically configures various components and dependencies based on the classpath and the configuration files. It analyzes the dependencies, detects the presence of certain frameworks or libraries, and configures them automatically. This saves developers from explicitly configuring each component.
  4. Embedded Servers: Spring Boot provides embedded servers like Tomcat or Jetty, which can be automatically configured based on the dependencies in the project. Developers do not need to manually deploy their application to an external server, as the application can be run as a standalone JAR file.
  5. Production-Ready Features: Spring Boot incorporates several production-ready features out of the box, such as health checks, metrics, logging, and performance monitoring. These features simplify the process of setting up a production-ready application without having to configure and integrate these features manually.


Overall, Spring Boot simplifies the configuration process by providing sensible defaults, externalizing configuration, automatically configuring dependencies, and offering production-ready features. This reduces the amount of manual configuration and speeds up the development process.


How does Spring Boot handle cross-cutting concerns such as logging and transaction management?

Spring Boot provides several features to handle cross-cutting concerns such as logging and transaction management:

  1. Logging: Spring Boot uses the Common Logging API, which provides a simple abstraction for various logging frameworks such as Logback, Log4j, and Java Util Logging. By default, Spring Boot includes Logback as the logging implementation. It automatically configures logging based on the chosen logging framework, and also provides the flexibility to customize logging configuration through properties in the application.properties or application.yml file.
  2. Transaction Management: Spring Boot integrates with the Spring Framework's transaction management capabilities. It supports two types of transaction management: programmatic and declarative. For programmatic transaction management, Spring Boot provides the TransactionTemplate class and the @Transactional annotation. The TransactionTemplate class allows you to manually control transactions in your code, whereas the @Transactional annotation simplifies transaction management by automatically starting and committing/rolling back transactions based on the specified conditions. For declarative transaction management, Spring Boot enables the use of declarative transaction management through the @EnableTransactionManagement annotation, which activates the transactional behavior defined by @Transactional annotations.


In addition to these features, Spring Boot also provides other utilities to handle cross-cutting concerns, such as security, caching, and error handling, through the use of various starter dependencies and auto-configuration.


What is the role of the Spring Boot Admin server?

The Spring Boot Admin server is a community project that provides a user interface for managing and monitoring Spring Boot applications. Its role is to:

  1. Monitor Spring Boot applications: The Spring Boot Admin server collects various metrics and health information from registered Spring Boot applications. It provides an overview of application status, including information about memory usage, CPU utilization, thread count, and more.
  2. Manage Spring Boot applications: The Spring Boot Admin server enables application management tasks such as starting, stopping, and restarting Spring Boot applications. It allows developers or administrators to control the lifecycle of individual applications.
  3. Alerting and notifications: The Spring Boot Admin server can be configured to send notifications or alerts when certain conditions occur, such as application failure, high CPU usage, or low memory. This helps in proactively identifying and resolving issues with Spring Boot applications.
  4. Logging and log aggregation: The Spring Boot Admin server provides a centralized view of application logs. It can collect log files from registered applications and display them in a consolidated manner. This makes it easier to troubleshoot application issues and analyze logs from multiple instances.
  5. Security and authentication: The Spring Boot Admin server allows for securing the access to the user interface and REST APIs using various authentication methods such as basic authentication, OAuth, and more. This ensures that only authorized users can access and manage the Spring Boot applications.


Overall, the Spring Boot Admin server plays a crucial role in providing a centralized management and monitoring solution for Spring Boot applications, helping in efficient application deployment, troubleshooting, and performance optimization.
